GaAs功率管
GaAs功率管，采用砷化镓工艺制造的射频功率放大器件。覆盖从1.2GHz到11.7GHz的宽频率范围，可提供从基础级到高功率级别的多种型号选择，适用于各种射频微波应用场景。
主要技术指标
频率范围：1.2 GHz ～ 11.7 GHz（多频段可选）
饱和输出功率：+30 dBm ～ +47.5 dBm （典型值范围 ）
增益： 7 dB ～ 12.5 dB（典型值范围 ）
附加效率：28% ～ 40%（典型值范围 ）
封装形式：IK/IB/IK-2/IKFP/IBFP
型号
| 型号 |
频率范围 （GHz） |
输出功率 （dBm） |
增益 （dB） |
效率 |
电压 |
平坦度 |
工作模式 |
封装 | ||
|
附加效率 |
η | 工作类型 | 脉冲规格 | |||||||
|
FPAP846844P2-1
|
4.20~ 4.40GHZ
|
33 | 10 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP846844P2-2
|
4.20~ 4.40GHZ
|
33 | 10 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP844838P8-1
|
4.40~ 5.00GHZ
|
39 | 9 | 40 | 10 | ±0.8 | CW | IB | ||
|
FPAP844838P18
|
4.40~ 5.00GHZ
|
42.5 | 9 | 37 | 10 | ±0.8 | CW | IK | ||
|
FPAP844838P45
|
4.40~ 5.00GHZ
|
46.5 | 8 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP835829P4-1
|
5.30~ 5.90GHZ
|
36.5 | 9.5 | 37 | 10 | ±0.8 | CW | IB | ||
|
FPAP835829P9-1
|
5.30~ 5.90GHZ
|
39.5 | 9.5 | 36 | 10 | ±0.8 | CW | IB | ||
|
FPAP835829P8-1
|
5.30~ 5.90GHZ
|
39 | 9 | 38 | 10 | ±0.8 | CW | IB | ||
|
FPAP835829P15-1
|
5.30~ 5.90GHZ
|
41.5 | 9.5 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP835829P18-1
|
5.30~ 5.90GHZ
|
42.5 | 10 | 36 | 10 | ±0.8 | CW | IK | ||
|
FPAP830824P16
|
5.80~ 6.40GHZ
|
42 | 8.5 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP830824P30
|
5.85~ 6.425GHZ
|
45 | 8 | 30 | 10 | ±0.8 | CW | IK | ||
|
FPAP830821P4-1
|
5.80~ 6.70GHZ
|
36 | 10 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP829824P4-1
|
5.90~ 6.40GHZ
|
36.5 | 10 | 37 | 10 | ±0.8 | CW | IB | ||
|
FPAP829824P4-1
|
5.90~ 6.40GHZ
|
36 | 10 | 40 | 10 | ±0.8 | CW | IB | ||
|
FPAP829824P9-1
|
5.90~ 6.40GHZ
|
39.5 | 10 | 37 | 10 | ±0.8 | CW | IB | ||
|
FPAP829824P8-1
|
5.90~ 6.40GHZ
|
39 | 9 | 40 | 10 | ±0.8 | CW | IB | ||
|
FPAP829824P18-1
|
5.90~ 6.40GHZ
|
42.5 | 10 | 40 | 10 | ±0.8 | CW | IK | ||
|
FPAP829824P30
|
5.90~ 6.40GHZ
|
45 | 8.5 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP824816P4-1
|
6.40~ 7.20GHZ
|
36.5 | 9.5 | 36 | 10 | ±0.8 | CW | IK | ||
|
FPAP824816P4-1
|
6.40~ 7.20GHZ
|
36 | 9 | 40 | 10 | ±0.8 | CW | IB | ||
|
FPAP824816P9-1
|
6.40~ 7.20GHZ
|
39.5 | 9.5 | 36 | 10 | ±0.8 | CW | IK | ||
|
FPAP824816P8-1
|
6.40~ 7.20GHZ
|
39 | 9 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP824816P25-1
|
6.40~ 7.20GHZ
|
44 | 9 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP820813P4-1
|
6.80~ 7.50GHZ
|
36 | 8 | 38 | 10 | ±0.8 | CW | IB | ||
|
FPAP820813P8-1
|
6.80~ 7.50GHZ
|
39 | 8 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP819814P25
|
6.90~ 7.40GHZ
|
44 | 7 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP818815P30
|
7.00~ 7.30GHZ
|
45 | 8 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP818814P4
|
7.00~ 7.40GHZ
|
36 | 8 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP818814P4-1
|
7~7.4GHz
|
36 | 9 | 35 | 10 | ±0.5 | CW | IB | ||
|
FPAP818814P20
|
7.00~ 7.40GHZ
|
43 | 7 | 40 | 10 | ±0.8 | CW | IB | ||
|
FPAP817815P4-1
|
7.10~ 7.30GHZ
|
36 | 9 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP817815P10-1
|
7.10~ 7.30GHZ
|
40 | 7.5 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP817809P14-1
|
7.10~ 7.90GHZ
|
41.5 | 8 | 40 | 10 | ±0.8 | CW | IK | ||
|
FPAP817803P6-1
|
7.10~ 8.50GHZ
|
38 | 8 | 40 | 10 | ±0.8 | CW | IB | ||
|
FPAP811803P8
|
7.70~ 8.50GHZ
|
39 | 8.5 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP811803P14-1
|
7.70~ 8.50GHZ
|
41.5 | 7.5 | 30 | 10 | ±0.8 | CW | IK | ||
|
FPAP811803P16
|
7.70~ 8.50GHZ
|
42 | 8 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP811803P20-1
|
7.70~ 8.50GHZ
|
43 | 6.5 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP808802P5
|
8.00~ 8.60GHZ
|
37 | 8 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP803793P13
|
8.50~ 9.50GHZ
|
41 | 7 | 31 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P2-1
|
8.50~ 9.60GHZ
|
33.5 | 7.5 | 30 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P2-1
|
8.50~ 9.60GHZ
|
33 | 7 | 28 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P3-1
|
8.50~ 9.60GHZ
|
35 | 7 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P4-1
|
8.50~ 9.60GHZ
|
36 | 8 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P5-1
|
8.50~ 9.60GHZ
|
37 | 7 | 38 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P8
|
8.50~ 9.60GHZ
|
39 | 7 | 38 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P10-1
|
8.50~ 9.60GHZ
|
39.5 | 6 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P9-1
|
8.50~ 9.60GHZ
|
39.5 | 6 | 30 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P13-1
|
8.50~ 9.60GHZ
|
41 | 7 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP803792P13-1
|
8.50~ 9.60GHZ
|
41 | 7 | 30 | 10 | ±0.8 | CW | IB | ||
|
FPAP803792P16
|
8.50~ 9.60GHZ
|
42 | 7 | 38 | 10 | ±0.8 | CW | IK | ||
|
FPAP803792P16-1
|
8.50~ 9.60GHZ
|
42 | 7 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP803792P20-1
|
8.50~ 9.60GHZ
|
43 | 6.5 | 35 | 10 | ±0.8 | CW | IK | ||
|
FPAP799792P25-1
|
8.90~ 9.60GHZ
|
44 | 6.5 | 30 | 10 | ±0.8 | CW | IK | ||
|
FPAP798788P5
|
9.00~ 10.00GHZ
|
36 | 8 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP798788P25
|
9.00~ 10.00GHZ
|
44 | 6.5 | 30 | 10 | ±0.8 | CW | IK | ||
|
FPAP793783P4-1
|
9.50~ 10.50GHZ
|
36 | 7.5 | 29 | 10 | ±0.8 | CW | IB | ||
|
FPAP793783P8-1
|
9.50~ 10.50GHZ
|
39 | 6.5 | 35 | 10 | ±0.8 | CW | IB | ||
|
FPAP793783P13-1
|
9.50~ 10.50GHZ
|
41 | 35 | 10 | ±0.8 | CW | IK | |||
|
FPAP793783P25
|
9.50~ 10.50GHZ
|
44 | 7 | 30 | 10 | ±0.8 | CW | IK | ||
|
FPAP791785P0
|
9.70~ 10.30GHZ
|
30 | 6.5 | 30 | 10 | ±0.8 | CW | IB | ||
|
FPAP781771P4-1
|
10.70~ 11.70GHZ
|
36 | 7 | 29 | 10 | ±0.8 | CW | IB | ||
|
FPAP781771P8-1
|
10.70~ 11.70GHZ
|
39 | 7 | 29 | 10 | ±0.8 | CW | IB | ||
|
FPAP781771P8-1
|
10.70~ 11.70GHZ
|
39 | 7 | 29 | 10 | ±0.8 | CW | IB | ||
|
FPAP781771P10-1
|
10.70~ 11.70GHZ
|
40 | 6 | 30 | 10 | ±0.8 | CW | IB | ||
|
FPAP781771P16-1
|
10.70~ 11.70GHZ
|
42 | 7 | 31 | 10 | ±0.8 | CW | IB | ||
