GaN功率管
GaN功率管，采用氮化镓HEMT工艺，覆盖0.7~7.1 GHz频率范围，具有高输出功率、高效率和高增益特性，支持连续波（CW）和脉冲两种工作模式。
主要技术指标
频率范围：0.7 ~ 7.1 GHz（多频段可选）
饱和输出功率：+37 dBm ~ +59 dBm
增益：9 dB ~ 18 dB
附加效率：28% ~ 60%
封装形式：IK / IK-2 / JF06F016 / C164-1F
型号
| 型号 |
频率范围 （GHz） |
输出功率 （dBm） |
增益 （dB） |
效率 |
电压 |
平坦度 |
工作模式 |
封装 | ||
|
附加效率 |
η | 工作类型 | 脉冲规格 | |||||||
|
FPANP881878P45 |
0.70~ 1.00GHz
|
46.5
|
14.5
|
60 |
28
|
±0.8
|
CW
|
IK-2 | ||
|
FPANP881873P65
|
0.70~ 1.50GHz
|
48
|
12
|
55
|
28
|
±0.8
|
CW
|
JF06F016 | ||
|
FPANP881872P80
|
0.75~ 1.525GHz
|
49
|
12
|
55
|
28
|
±0.8
|
CW
|
JF06F016 | ||
|
FPANP880879P50
|
860~ 930MHZ
|
47
|
13
|
55
|
28
|
±0.8
|
CW
|
IK-2 | ||
|
FPANP880868P16
|
0.80~ 2.00GHz
|
42
|
10
|
45
|
28
|
±0.8
|
CW
|
IK-2 | ||
|
FPANP880868P30
|
0.80~ 2.00GHz
|
45
|
12
|
45
|
48
|
±0.8
|
CW |
IK-2 | ||
|
FPANP880868P40
|
0.80~ 2.00GHz
|
46
|
10
|
50
|
28
|
±1
|
CW
|
IK-2 | ||
|
FPANP880868P100
|
0.80~ 2.00GHz
|
50
|
10
|
45
|
32
|
±0.8
|
CW |
|||
|
FPANP879876P5
|
0.96~ 1.24GHz
|
37
|
16
|
50
|
50
|
±0.8
|
Pulse
|
|||
|
FPANP879876P6
|
0.96~ 1.25GHz
|
38
|
14
|
55
|
28
|
±0.8
|
CW
|
|||
|
FPANP879876P80
|
0.96~ 1.25GHz
|
49
|
14
|
55
|
32 |
±0.8
|
CW
|
|||
|
FPANP879876P100
|
0.96~ 1.23GHz
|
50
|
13
|
50
|
32
|
±0.8
|
Pulse
|
|||
|
0.96~ 1.25GHz
|
50
|
14
|
55
|
28
|
±0.8
|
CW | ||||
|
0.96~ 1.24GHz
|
50
|
16
|
50
|
50
|
±0.8
|
Pulse | ||||
|
FPANP879876P250
|
0.96~ 1.215GHz
|
54
|
13
|
55
|
50
|
±0.8
|
Pulse | |||
|
FPANP879876P500
|
0.96~ 1.24GHz
|
57
|
14
|
50
|
50
|
±0.8
|
||||
|
FPANP879876P630
|
0.96~ 1.225GHz
|
58
|
13.5
|
60
|
50
|
±0.8
|
||||
|
FPANP879874P30
|
0.90~ 1.40GHz
|
45
|
14
|
60
|
50
|
±0.8
|
||||
|
FPANP878877P200
|
1.00~ 1.10GHz
|
53
|
14
|
55
|
28
|
±0.8
|
||||
|
FPANP878877P250
|
1.00~ 1.10GHz
|
54
|
14
|
55
|
50
|
±0.8
|
||||
|
FPANP878877P795
|
1.00~ 1.10GHz
|
59
|
16
|
55
|
50
|
±0.8
|
||||
|
FPANP878872P20
|
1.00~ 1.60GHz
|
43
|
14
|
55
|
28
|
±0.8
|
||||
|
FPANP878868P5
|
1.00~ 2.00GHz
|
37
|
28
|
35
|
28
|
±0.8
|
||||
|
1.00~ 2.00GHz
|
37
|
13
|
45
|
28
|
±0.8
|
|||||
|
FPANP878868P30
|
1.00~ 2.00GHz
|
45
|
12
|
50
|
28
|
±0.8
|
||||
|
FPANP878868P50
|
1.00~ 2.00GHz
|
47
|
10
|
45
|
32
|
±0.8
|
||||
|
FPANP877875P10
|
1.10~ 1.30GHz
|
40
|
14
|
50
|
28
|
±0.8
|
||||
|
FPANP877872P80
|
1.10~ 1.60GHz
|
49
|
10
|
50
|
28
|
±0.8
|
||||
|
FPANP876874P20
|
1.20~ 1.40GHz
|
43
|
14
|
60
|
28
|
±0.8
|
||||
|
FPANP876874P65
|
1.20~ 1.40GHz
|
48
|
13
|
50
|
32
|
±0.8
|
||||
|
FPANP876874P125
|
1.20~ 1.40GHz
|
51
|
13
|
50
|
32
|
±0.8
|
||||
|
1.20~ 1.40GHz
|
51
|
13
|
50
|
50
|
±0.8
|
|||||
|
FPANP876874P160
|
1.20~ 1.40GHz
|
52
|
13
|
55
|
50
|
±0.8
|
||||
|
FPANP876874P500
|
1.20~ 1.40GHz
|
57
|
16
|
55
|
50
|
±0.8
|
||||
|
FPANP876874P700
|
1.20~ 1.40GHz
|
58.5
|
13.5
|
60
|
48
|
±0.8
|
||||
|
FPANP876872P40
|
1.20~ 1.60GHz
|
46
|
11
|
55
|
28
|
±0.8
|
||||
|
FPANP875873P4
|
1.30~ 1.50GHz
|
36
|
14
|
30
|
28
|
±0.8
|
||||
|
FPANP875873P10
|
1.30~ 1.50GHz
|
40
|
14
|
50
|
28
|
±0.8
|
||||
|
FPANP875873P25
|
1.30~ 1.50GHz
|
44
|
14
|
50
|
28
|
±0.8
|
||||
|
FPANP875873P40
|
1.30~ 1.50GHz
|
46
|
12
|
50
|
28
|
±0.8
|
||||
|
FPANP875871P40
|
1.35~ 1.70GHz
|
46
|
13
|
50
|
28
|
±0.8
|
||||
|
FPANP875870P5
|
1.30~ 1.80GHz
|
37
|
14
|
55
|
28
|
±0.8
|
||||
|
FPANP875870P10
|
1.30~ 1.80GHz
|
40
|
12
|
55
|
28
|
±0.8
|
||||
|
FPANP875870P20
|
1.30~ 1.80GHz
|
43
|
13
|
55
|
28
|
±0.8
|
||||
|
FPANP875870P40
|
1.30~ 1.80GHz
|
46
|
13
|
50
|
28
|
±0.8
|
||||
|
FPANP875870P50
|
1.30~ 1.80GHz
|
47
|
12
|
50
|
28
|
±0.8
|
||||
|
FPANP875870P65
|
1.35~ 1.75GHz
|
48
|
13
|
55
|
28
|
±0.8
|
||||
|
1.35~ 1.80GHz
|
48
|
13
|
50
|
28
|
±0.8
|
|||||
